Installation Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.

Install the radiator inlet hose to the engine (5).
Reposition the inlet radiator hose clamp (3).

Fig 1: Installing Radiator Inlet Hose To Engine (Body Vin Code 6 LM4)
Courtesy of GENERAL MOTORS CORP.
Install the inlet radiator hose (2) to the radiator (1).
Reposition the inlet radiator hose clamp (3).
Lower the vehicle.
Fill the cooling system. Refer to DRAINING AND FILLING COOLING SYSTEM (BODY VIN CODE 6) or DRAINING AND FILLING COOLING SYSTEM (BODY VIN CODE 3) .

Fig 2: Installing Inlet Radiator Hose To Radiator (Body Vin Code 6 LM4)
Courtesy of GENERAL MOTORS CORP.
