Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise the vehicle. Refer to LIFTING AND JACKING THE VEHICLE in General Information.
  2. Remove the engine shield. Refer to ENGINE PROTECTION SHIELD REPLACEMENT
  3. Remove the electrical connector from the oil pressure switch.
  4. Remove the oil pressure switch.
    Fig 1: Removing Oil Pressure Switch
    G02128594Courtesy of GENERAL MOTORS CORP.
