Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle   in General Information.
  2. Remove the tire and wheel. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION  in Tires and Wheels.
  3. Remove the brake rotor. Refer to Brake Rotor Replacement - Front   in Disc Brakes.
  4. Remove the ABS sensor mounting bolt from the wheel hub and bearing.
  5. Remove the ABS sensor from the wheel hub and bearing.
    Fig 1: Removing ABS Sensor From Wheel Hub And Bearing
    G01597361Courtesy of GENERAL MOTORS CORP.
  6. Remove the wheel hub and bearing to the steering knuckle mounting bolts.
    Fig 2: Removing Wheel Hub And Bearing To Steering Knuckle Mounting Bolts
    G01597362Courtesy of GENERAL MOTORS CORP.
  7. Remove the wheel hub and bearing from the steering knuckle.
  8. Remove the splash shield from the steering knuckle.
    Fig 3: Removing Wheel Hub And Bearing From Steering Knuckle
    G01597363Courtesy of GENERAL MOTORS CORP.
