Removal Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2004 Oldsmobile Bravada, 2004 GMC Envoy XUV, 2004 GMC Envoy XL, 2004 GMC Envoy, and 2004 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle in General Information.
  2. Disconnect the electrical connector from the A/C refrigerant pressure sensor. The connector is accessible through the lower control arm.
    3. Fig 1: A/C Refrigerant Pressure Sensor
    GM735912Courtesy of GENERAL MOTORS CORP.
  3. Remove the A/C refrigerant pressure sensor from the compressor hose block.
  4. Remove and discard the O-ring seal from the A/C refrigerant pressure sensor.
