Removal Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2004 Oldsmobile Bravada, 2004 GMC Envoy XUV, 2004 GMC Envoy XL, 2004 GMC Envoy, and 2004 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Removing Latch Bracket Assembly-To-Endgate Bolts
    GM902604Courtesy of GENERAL MOTORS CORP.
  1. Open the endgate (drop mode).
  2. Remove the bolts retaining the latch bracket assembly to the endgate.
  3. Remove the latch bracket assembly from the endgate.
  4. Disconnect the electrical connector from the latch assembly.
    5. Fig 2: Removing Endgate Latch From Latch Bracket Assembly
    GM1229116Courtesy of GENERAL MOTORS CORP.
  5. Remove the screws retaining the latch assembly to the latch bracket.
  6. Remove the latch assembly from the bracket.
