Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  1. Install the child seat anchor bracket (4) to the vehicle. Secure the bracket with the bolt (3).

    Tighten

    Tighten the child seat anchor bracket bolt to 2 N.m (15 lb ft).

  2. Install the rear access panel (2).
    Fig 1: Installing Child Seat Anchor Bracket, Bolt & Rear Access Panel
    G01435178Courtesy of GENERAL MOTORS CORP.
