Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear seat assembly. Refer to SEAT REPLACEMENT - REAR in Seats.
  2. Remove the bolt (2).
  3. Remove the rear seat hinge (3).
  4. Gently pry the rear body side lower garnish molding plastic retainers and remove the molding (1) from the vehicle.
    Fig 1: Removing Rear Seat Hinge Bolt
    G01434963Courtesy of GENERAL MOTORS CORP.
