Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Place the rear seat to the anchors.
    NOTE: Refer to FASTENER NOTICE .
  2. Install the lower seat bolts (3).

    Tighten

    Tighten the lower seat bolts (3) to 18 N.m (13 lb ft).

  3. Install center seat belt retractor, if removed. Refer to SEAT BELT RETRACTOR REPLACEMENT - CENTER REAR in Seat Belts.
  4. Install the seat back hinge bolts (2).

    Tighten

    Tighten the seat back hinge bolts (2) to 18 N.m (13 lb ft).

  5. Install the plastic hinge covers (1).
  6. Install the rear seat to its original position.
    Fig 1: Installing Plastic Hinge Covers & Seat Back Hinge Bolts
    G01434897Courtesy of GENERAL MOTORS CORP.
