Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear side door trim. Refer to TRIM PANEL REPLACEMENT - SIDE REAR DOOR  .
  2. Straighten the retaining tabs (3) and remove the inner sealing strip (1) from the rear door trim panel (2).
    Fig 1: Removing Inner Sealing Strip From Rear Door Trim Panel
    G01434726Courtesy of GENERAL MOTORS CORP.
