Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front side door trim. Refer to TRIM PANEL REPLACEMENT - SIDE FRONT DOOR  .
  2. Straighten the retaining tabs (3) and remove the inner sealing strip (1) from the front door trim panel (2).
    Fig 1: Removing Inner Sealing Strip From Front Door Trim Panel
    G01434724Courtesy of GENERAL MOTORS CORP.
