Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and suitably support the hood.
  2. Remove the hood front bumper (1) from the vehicle by unscrewing.
    Fig 1: Removing Hood Front Bumper From Vehicle
    G01434515Courtesy of GENERAL MOTORS CORP.
