Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Connect the speaker electrical connector.
  2. Install the speaker (1) to the door. Secure the speaker with 3 rivets (2).
  3. Install the rear door trim panel. Refer to TRIM PANEL REPLACEMENT - SIDE REAR DOOR in Doors.
    Fig 1: Installing Rear Door Speaker To Vehicle
    G01433935Courtesy of GENERAL MOTORS CORP.
