Radio/Audio System Description and Operation: Notes

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.

The following list shows the radios available for this vehicle:

U1P - AM/FM, Internal single CD player, and RDS
UC6 - AM/FM, Internal six CD player, and RDS
U1A - Navigation Radio, remote six CD player, AM/FM, and RDS
UZ6 - Audio amplifier with 6 speakers (only available with UC6)

Fig 1: Radio/Audio System Description And Operation Chart (Radio) (1 Of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 2: Radio/Audio System Description And Operation Chart (Radio) (2 Of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 3: Radio/Audio System Description And Operation Chart (Compact Disc) (1 Of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 4: Radio/Audio System Description And Operation Chart (Compact Disc) (2 Of 2)

Courtesy of GENERAL MOTORS CORP.
