Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the right side fender flare. Refer to FLARE REPLACEMENT - FRONT FENDER in Exterior Trim.
  2. Remove the right side wheel house panel. Refer to WHEELHOUSE PANEL REPLACEMENT in Body Front End.
  3. Disconnect the 2 washer pump electrical connectors (1).
  4. Disconnect the washer pump hoses (4) from the washer pumps (3).
  5. Remove the 3 bolts which secure the windshield washer solvent container (2).
  6. Squeeze tabs on filler neck and pull down to remove washer solvent container (2) from vehicle.
  7. Drain solvent from washer solvent container (2).
  8. Remove the washer pumps (1) from the washer solvent container (2).
    Fig 1: Removing Washer Solvent Container
    G01433830Courtesy of GENERAL MOTORS CORP.
