Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the 2 lower plastic retainers which secure the hood insulator. Fold back the bottom of the hood insulator (4) in order to gain access to the windshield washer nozzle hose (1) and the rear of the windshield washer nozzle (2).
  2. Remove the hose (1) from the nozzle (2).
    Fig 1: Removing Hose From Nozzle
    G01433834Courtesy of GENERAL MOTORS CORP.
  3. Press together the nozzle retaining tabs and remove the nozzle (1) from the hood (2).
    Fig 2: Removing Nozzle From Hood
    G01433835Courtesy of GENERAL MOTORS CORP.
