Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front carpet. Refer to CARPET REPLACEMENT in Interior Trim.
  2. Remove the rear floor outlet duct (3) from the HVAC module (1).
  3. Remove the rear floor outlet duct from the vehicle.
    Fig 1: Removing Left Rear Floor Outlet Duct
    G01545494Courtesy of GENERAL MOTORS CORP.
