Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the two screws (1) from the outlet duct (5).
  2. Remove the outlet duct (5) from the HVAC module (2).
Fig 1: Removing Left Floor Outlet Duct
G01545488Courtesy of GENERAL MOTORS CORP.
