Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the lower radiator air baffle. Refer to RADIATOR AIR BAFFLE AND DEFLECTOR REPLACEMENT - LOWER  .
  2. Remove the retainers from the upper radiator air baffle (2).
  3. Remove the upper radiator air baffle (2).
    Fig 1: Removing Upper Radiator Air Baffle
    G02084101Courtesy of GENERAL MOTORS CORP.
