Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the upper radiator air baffle (2).
  2. Install the upper radiator air baffle retainers.
  3. Install the lower radiator air baffle. Refer to RADIATOR AIR BAFFLE AND DEFLECTOR REPLACEMENT - LOWER  .
    Fig 1: Installing Upper Radiator Air Baffle
    G02084102Courtesy of GENERAL MOTORS CORP.
