Section 1229 (Manual Transmission - NV 1500)
>>
Schematic & Routing Diagrams
>>
Manual Transmission Schematic Icons
Manual Transmission Schematic Icons
WARNING:
This page is about a different car, the 2002 GMC Sonoma and 2002 Chevrolet S10 Pickup. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Manual Transmission Schematic Icons
Courtesy of GENERAL MOTORS CORP.
