Removal Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
  1. Pry carefully at the lower edge of the rear compartment lid release switch to release the locking tab.
  2. Disconnect the electrical connector from the switch.
  3. Remove the switch.
    Fig 1: Rear Compartment Lid Switch
    G01451974Courtesy of GENERAL MOTORS CORP.
