Installation Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
  1. Connect the electrical connector to the rear compartment lid release switch.
  2. Install the switch.

    Align the switch to the opening in the trim panel, then push to secure.

    Fig 1: Rear Compartment Lid Switch
    G01451975Courtesy of GENERAL MOTORS CORP.
