Installation Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION: In order to avoid personal Injury or vehicle damage when you repair or replace the carpet, use the same thickness and material size as the original Installation. Always return the carpet to the original location.

Position the carpet under the speaker grilles and under the rear corner carpet trim panels.

Fig 1: Identifying Rear Compartment Carpet For Installing
Courtesy of GENERAL MOTORS CORP.
Install the latch striker retainers to the cover of the center stowage compartment.
Install the carpet retainers to the forward stowage brackets of the roof lift-off panel.
Install the brackets to the roof lift-off panel. Rotate the brackets 90 degrees counterclockwise to secure.

Fig 2: Installing Carpet Retainers To Forward Stowage Brackets Of Roof Lift-Off Panel
Courtesy of GENERAL MOTORS CORP.
Install the covers to the right, left, and center rear stowage compartments.

Fig 3: Installing Covers To Right, Left & Center Rear Stowage Compartments
Courtesy of GENERAL MOTORS CORP.
