Installation Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the hanger reinforcement, if necessary.
  2. Install the push-on retainer, if necessary.
    NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  3. Install the muffler hanger and nuts.

    Tighten

    Tighten the muffler hanger nuts to 16 N.m (12 lb ft).

  4. Install the muffler. Refer to MUFFLER REPLACEMENT - LEFT  or MUFFLER REPLACEMENT - RIGHT .
    Fig 1: Muffler Hanger & Nuts
    G01971231Courtesy of GENERAL MOTORS CORP.
