Special Tools

WARNING: This page is about a different car, the 2004 GMC Sierra, 2004 GMC Cab & Chassis Sierra, 2004 Chevrolet Silverado, and 2004 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J 2222-C Wheel Bearing Nut Wrench
Courtesy of GENERAL MOTORS CORP.	J 2619-01 Slide Hammer
Courtesy of GENERAL MOTORS CORP.	J 7818 Inner Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 8001 Dial Indicator Set
Courtesy of GENERAL MOTORS CORP.	J 8092 Universal Driver Handle - 3/4 inch - 10
Courtesy of GENERAL MOTORS CORP.	J 8608 Rear Pinion Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 8611-01 Rear Pinion Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 8614-01 Flange and Pulley Holding Tool
Courtesy of GENERAL MOTORS CORP.	J 21128 Axle Pinion Oil Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 21777-86 Side Bearing Disc, 9.5 in Axle, 2 Required
Courtesy of GENERAL MOTORS CORP.	J 21784 Side Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 22306 Pinion Cup Bearing Installer - Rear
Courtesy of GENERAL MOTORS CORP.	J 22388 Pinion Oil Seal Installer - Rear
Courtesy of GENERAL MOTORS CORP.	J 22536 Pinion Driver
Courtesy of GENERAL MOTORS CORP.	J 22761 Differential Side Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 22779 Side Bearing Backlash Gage
Courtesy of GENERAL MOTORS CORP.	J 22888-D Side Bearing Remover Kit
Courtesy of GENERAL MOTORS CORP.	J 22912-01 Split-Plate Bearing Puller
Courtesy of GENERAL MOTORS CORP.	J 23690 Axle Shaft Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 24385-01 Axle Housing Spreader
Courtesy of GENERAL MOTORS CORP.	J 24426 Wheel Bearing Race Installer - Outer
Courtesy of GENERAL MOTORS CORP.	J 24427 Wheel Bearing Race Installer - Outer
Courtesy of GENERAL MOTORS CORP.	J 24429 Side Bearing Backlash Spanner
Courtesy of GENERAL MOTORS CORP.	J 24430 Differential Side Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 24433 Pinion Cone and Side Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 25025 Guide Pins
Courtesy of GENERAL MOTORS CORP.	J 25588 Side Bearing Shim Installer
Courtesy of GENERAL MOTORS CORP.	J 29709 Wheel Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 29710 Differential Side Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 29712 Wheel Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 29713 Axle Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 33049 Camshaft Bearing Service Set
Courtesy of GENERAL MOTORS CORP.	J 34925 Pinion Setting Gage Kit
Courtesy of GENERAL MOTORS CORP.	J 34178 Spreader Gage Adapter
Courtesy of GENERAL MOTORS CORP.	J 36597 Spreader Gage Adapter
Courtesy of GENERAL MOTORS CORP.	J 36614 Inner Pinion Bearing Installer (9.5 in Ring Gear)
Courtesy of GENERAL MOTORS CORP.	J 37624 Pinion Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 42176 Universal Driver Handle - Non-Threaded
Courtesy of GENERAL MOTORS CORP.	J 44412 Pinion Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 44414 Pinion Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 44416 Pinion Shim Selector Kit
Courtesy of GENERAL MOTORS CORP.	J 44417 Rear Pinion Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 44419 Hub Outer Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 44420 Differential Bearing and Hub Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 44421 Pinion Remover
Courtesy of GENERAL MOTORS CORP.	J 44685 Rear Axle Seal and Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 45108 Pinion Setting Gage Block
Courtesy of GENERAL MOTORS CORP.	J 45177 Differential Seal Installer - Inner
Courtesy of GENERAL MOTORS CORP.	J 45692 Pinion Shim Selector Kit - Dana Axles
Courtesy of GENERAL MOTORS CORP.	J 45703 Pinion Bearing Race Remover - Dana 248
Courtesy of GENERAL MOTORS CORP.	J 45704 Pinion Bearing Race Installer - Dana 248
Courtesy of GENERAL MOTORS CORP.	J 45705 Pinion Bearing Race Remover - Dana 248/267
Courtesy of GENERAL MOTORS CORP.	J 45710 Pinion Bearing Oil Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 45870 Pinion Bearing Cup Installer
Courtesy of GENERAL MOTORS CORP.	J 45711 Differential Side Bearing Remover - Dana 248
Courtesy of GENERAL MOTORS CORP.	J 45871 Pinion Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 45900 Differential Side Bearing Installer - Dana Axles
