Crankshaft Balancer Installation
WARNING: This page is about a different car, the 2004 GMC Sierra, 2004 GMC Cab & Chassis Sierra, 2004 Chevrolet Silverado, and 2004 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
Tools Required
- J 42845 Crankshaft Balancer Installer. See Special Tools and Equipment .
- J 42847 Flywheel Holding Tool. See Special Tools and Equipment .
- Ensure that the teeth of the flywheel holding tool engage the engine flywheel teeth.
- The balancer should be positioned onto the end of the crankshaft as straight as possible prior to tool installation.
- Install the J 42847
(1) to the starter bolt holes.
Tighten: Tighten the J 42847 bolts to 50 N.m (37 lb ft).
- Install the balancer onto the end of the crankshaft.
- Use the J 42845 (1) in order to install the balancer.
- Tighten the J 42845 until the crankshaft balancer is completely seated against the crankshaft sprocket.
- Remove the J 42845 from the crankshaft.
- Install the crankshaft balancer washer and bolt.
Tighten: Tighten the crankshaft balancer bolt to 255 N.m (189 lb ft).
- Remove the J 42847 (1).
NOTE:
Refer to Fastener Notice
in Cautions and Notices.
IMPORTANT:
IMPORTANT:
Apply grease or clean engine oil to the inside of the crankshaft balancer or the end of the crankshaft, to prevent galling during assembly.
IMPORTANT:
Apply the lubricant that comes with J 42845
each time the tool is used. Failure to lubricate J 42845
may prevent the balancer from installing completely.
NOTE:
Ensure the crankshaft balancer is installed to the proper depth. The crankshaft balancer nose must be seated against the crankshaft sprocket. Failure to install the crankshaft balancer properly may result in improper torque to the crankshaft balancer bolt. An improperly torqued crankshaft balancer bolt may loosen causing serious engine damage.
