Removal Procedure

IMPORTANT: The steering column support is not serviceable.
  1. Remove the instrument panel. Refer to IP CARRIER REPLACEMENT .
  2. Remove the brake switch. Refer to STOP LIGHT SWITCH in DISC & DRUM brakes article.
  3. Remove the brake booster pushrod from the brake pedal. Refer to VACUUM BRAKE BOOSTER in DISC & DRUM brakes article.
  4. Remove the clutch master cylinder pushrod from the clutch pedal, if equipped. Refer to CLUTCH MASTER CYLINDER & RESERVOIR in CLUTCHES article.
  5. Remove the following steering column support fasteners:
    • The 4 flange nuts.
    • The 2 bolts.
  6. Remove the brake pedal from the steering column support. Refer to BRAKE PEDAL in DISC & DRUM article.
    Fig 1: Locating Steering Column Support Fasteners
    G01842913Courtesy of GENERAL MOTORS CORP.
