Installation Procedure

  1. Connect the electrical connector.
  2. Install the temperature sensor by sliding the temperature sensor downward.
  3. Install the radiator grille. Refer to GRILLE REPLACEMENT (GMC) or GRILLE REPLACEMENT (CHEVROLET) in EXTERIOR TRIM.
    Fig 1: Locating Temperature Sensor
    G01842889Courtesy of GENERAL MOTORS CORP.
