Removal Procedure

  1. Remove the top and bottom push-pin retainers from the rear side door weatherstrip.
  2. Remove the weatherstrip from the rear door by gently pulling the weatherstrip away from the door.
    Fig 1: Removing Top And Bottom Push-Pin Retainers From Rear Side Door Weatherstrip - Rear Side Door - Extended Cab (Third Door)
    G01841633Courtesy of GENERAL MOTORS CORP.
