Installation Procedure

  1. Install the liftgate striker.
  2. Install any spacers to the vehicle.
  3. Install the liftgate striker backing plate.
    NOTE: Refer to FASTENER NOTICE in GM VEHICLES CAUTIONS & NOTICES article.
  4. Install the bolts that retain the liftgate striker to the vehicle.

    Tighten

    Tighten the bolts to 22 N.m (16 lb ft).

    Fig 1: Locating Liftgate Lock Striker
    G01841898Courtesy of GENERAL MOTORS CORP.
