Installation Procedure

  1. Install the endgate window latch.

    Ensure that the latch is properly aligned with the marks made during disassembly.

    NOTE: Refer to FASTENER NOTICE in GM VEHICLES CAUTIONS & NOTICES article.
  2. Install the nuts that retain the endgate window latch to the endgate window latch support.

    Tighten

    Tighten the nuts to 10 N.m (88 lb in).

    Fig 1: Locating Endgate Window Latch Components
    G01841878Courtesy of GENERAL MOTORS CORP.
  3. Connect the electrical connectors, as needed.
  4. Install the endgate cover. Refer to END GATE COVER REPLACEMENT .
