Installation Procedure

  1. Position the endgate handle assembly on the endgate.
  2. Install the endgate handle assembly to the endgate with 2 rivets using a J 34940  .
    NOTE: Refer to FASTENER NOTICE in GM VEHICLES CAUTIONS & NOTICES article.
  3. Install the screws that retain the inside handle to the endgate handle assembly.

    Tighten

    Tighten the screws to 2.8 N.m (25 lb in).

    Fig 1: Locating Rear Door Inside Handle Components
    G01841860Courtesy of GENERAL MOTORS CORP.
