Installation Procedure

NOTE: Refer to FASTENER NOTICE in GM VEHICLES CAUTIONS & NOTICES article.

Install the wiper arm park ramp under the wiper arm and onto the vehicle with two screws.
Tighten

Tighten two screws to 9 N.m (80 lb in).

Fig 1: Locating Rear Wiper Park Ramp
Courtesy of GENERAL MOTORS CORP.
Install the interior trim panel. Refer to TRIM PANEL REPLACEMENT - END GATE or TRIM PANEL REPLACEMENT - LIFT GATE in BODY REAR END article.
