Removal Procedure

  1. Remove the door trim panel. Refer to TRIM PANEL REPLACEMENT - SIDE REAR DOOR (UTILITY) or TRIM PANEL REPLACEMENT - SIDE REAR DOOR (EXTENDED CAB P/U ONLY) in DOORS.
  2. Remove the radio rear side door speaker retaining rivets.
    Fig 1: Locating Front Side Door Speaker Components
    G01841035Courtesy of GENERAL MOTORS CORP.
  3. Remove the radio rear side door speaker.
  4. Disconnect the electrical connector.
