Removal Procedure

  1. Open the endgate.
  2. Remove the screws that retain the inside handle to the endgate handle assembly.
  3. Drill out the rivets that retain the endgate handle assembly to the endgate.
  4. Remove the endgate handle assembly from the endgate.
    Fig 1: Locating Rear Door Inside Handle Components
    G01841859Courtesy of GENERAL MOTORS CORP.
