Left Axle Shaft Oil Seal: Reassembly

NOTE: When drive axle is removed from transaxle for any reason, inspect axle sealing surface (tripot shank) for corrosion. If corrosion is evident, clean surface with 320-grit cloth or equivalent. Clean off any remaining debris with ATF. Wipe surface dry and reinstall drive axle free of any build up.

Install NEW left axle shaft oil seal onto Left Side Axle Seal Installer (J-34115). Using left side axle seal installer and mallet, install left side axle oil seal assembly. See Fig 1.

Fig 1: Installing Left Side Axle Oil Seal
G00073369Courtesy of GENERAL MOTORS CORP.
