Removal Procedure

  1. Remove the oil pan. Refer to Oil Pan Replacement  .
  2. Remove the thermo element pins and washers (120 and 123).
  3. Remove the thermo element (121) and the thermo element plate (122).
    Fig 1: Removing Thermo Element, Pins & Washers
    G01812551Courtesy of GENERAL MOTORS CORP.
