Draining Procedure

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and support the vehicle. Refer to LIFTING & JACKING VEHICLE .
  2. Clean any dirt from around the differential drain plug (2).
  3. Position a drain pan under drain plug.
  4. Remove the drain plug (2) and gasket from the differential and drain the oil.
    Fig 1: Removing Differential Drain Plug
    G01827263Courtesy of GENERAL MOTORS CORP.
