Installation Procedure

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Auxiliary Blower Motor Resistor Assembly
    G01828080Courtesy of GENERAL MOTORS CORP.
  1. Install the auxiliary blower motor resistor to the auxiliary HVAC module assembly.
    NOTE: Refer to FASTENER NOTICE .
  2. Install the auxiliary blower motor resistor screws.

    Tighten

    Tighten the screws to 1.6 N.m (14 lb in).

  3. Connect the auxiliary blower motor resistor electrical connector.
  4. Install the accessory panel from the left rear quarter trim panel. Refer to ACCESSORY PANEL REPLACEMENT - REAR .
