Section 908 (HVAC Systems - Manual): Specifications
WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
Fastener Tightening Specifications
| Application |
Specification |
| Metric |
English |
| Actuator Retaining Screws, All |
1.6 N.m |
14 lb in |
| Auxiliary Blower Switch Retaining Screws |
2.5 N.m |
22 lb in |
| HVAC Control Module Retaining Screws |
2.5 N.m |
22 lb in |
Courtesy of GENERAL MOTORS CORP.
