Diagnostic Aids

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.

Inspect for a short to voltage or a short to ground in the seat belt indicator supply circuit circuit.
Inspect for an internal short to voltage or a short to ground within the IPC.

Test Description

The numbers below refer to the step numbers on the diagnostic table.

5. This step tests to see if there is a short to voltage in the seat belt indicator supply voltage circuit
7. This step tests to see if there is no open, high resistance, or a short to ground in the seat belt indicator supply voltage circuit

Fig 1: DTC 001 (1 Of 2)
Courtesy of GENERAL MOTORS CORP.

Fig 2: DTC 001 (2 Of 2)

Courtesy of GENERAL MOTORS CORP.
