Installation Procedure

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Installing Push-In Retainers & Front Energy Absorber
G01813806Courtesy of GENERAL MOTORS CORP.
  1. Align the rear impact bar to the frame rail.
    NOTE: Refer to FASTENER NOTICE .
  2. Install the rear impact bar bolts to the frame rail.

    Tighten

    Tighten the bolts to 50 N.m (36 lb ft).

  3. Install the energy absorber to the rear impact bar.
    Fig 2: Installing Impact Bar Bolts & Frame Rail
    G01813807Courtesy of GENERAL MOTORS CORP.
  4. Install the push-in retainers to the rear energy absorber.
  5. Install the rear bumper fascia. Refer to Fascia Replacement - Rear Bumper (Oldsmobile)  or Fascia Replacement - Rear Bumper (Pontiac) .
