Installation Procedure

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Align the front energy absorber to the front bumper fascia and push in to lock into place.
  2. Install the front bumper fascia. Refer to Fascia Replacement - Front Bumper (Pontiac)  or Fascia Replacement - Front Bumper (Chevrolet)  or Fascia Replacement - Front Bumper (Oldsmobile) .
    Fig 1: Installing Front Energy Absorber & Front Bumper Fascia
    G01813787Courtesy of GENERAL MOTORS CORP.
