Removal Procedure

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim panel. Refer to Trim Panel Replacement - Side Front Door .
  2. Remove the front door water deflector. Refer to Water Deflector Replacement - Front Door .
  3. Remove the front door conduit. Refer to Rubber Conduit Replacement - Front Door .
  4. Remove the front door window belt inner sealing strip. Refer to Sealing Strip Replacement - Front Door Window Belt Inner .
  5. Remove the front door window weatherstrip. Refer to Weatherstrip Replacement - Front Door Window .
    Fig 1: Removing Front Door Window Weatherstrip
    G01814042Courtesy of GENERAL MOTORS CORP.
  6. Remove the front door window. Refer to Window Replacement - Front Door .
  7. Remove the outside rearview mirror. Refer to Mirror Replacement - Power (With Turn Signal Indicator)  or Mirror Replacement - Power (Without Turn Signal Indicator) .
  8. Remove the front door module. Refer to Door Module Replacement - Front .
  9. Remove the front door outside handle. Refer to Door Handle Replacement - Front Outside .
  10. Remove the front door lock. Refer to Lock Replacement - Front Door .
  11. Remove the front door window belt outer sealing strip. Refer to Sealing Strip Replacement - Front Door Window Belt Outer .
  12. Remove the front door window run channel. Refer to Window Run Channel Replacement - Front Door .
  13. Remove the front door molding. Refer to MOLDING REPLACEMENT - DOOR BODY SIDE .
  14. Remove the front door hinges. Refer to Hinge Replacement - Front Door .
  15. With an assistant, remove the front door from the body.
