Removal Procedure

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the powersliding door.
  2. Using the J 38778,  remove the sliding door jamb contact plate push-in retainers.
  3. Remove the sliding door jamb contact plate from the pillar.
  4. Disconnect the sliding door jamb contact plate electrical connector.
    Fig 1: Removing Sliding Door Jamb Contact Plate
    G01814128Courtesy of GENERAL MOTORS CORP.
