Special Tools

WARNING: This page is about a different car, the 2004 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J 3049-A Valve Lifter Remover
Courtesy of GENERAL MOTORS CORP.	J 6125-1B Slide Hammer
Courtesy of GENERAL MOTORS CORP.	J 7872 Magnetic Base Dial Indicator Set
Courtesy of GENERAL MOTORS CORP.	J 8037 Piston Ring Compressor
Courtesy of GENERAL MOTORS CORP.	J 8062 Valve Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 8087 Cylinder Bore Gage
Courtesy of GENERAL MOTORS CORP.	J 8089 Carbon Removing Brush
Courtesy of GENERAL MOTORS CORP.	J 8433-1 Puller Bar
Courtesy of GENERAL MOTORS CORP.	J 8520 Cam Lobe Lift Indicator
Courtesy of GENERAL MOTORS CORP.	J 9666 Valve Spring Tester
Courtesy of GENERAL MOTORS CORP.	J 21867 Pressure Gage
Courtesy of GENERAL MOTORS CORP.	J 22794 Spark Plug Port Adapter
Courtesy of GENERAL MOTORS CORP.	J 24086-C Piston Pin Remover/Installer Set
Courtesy of GENERAL MOTORS CORP.	J 24270 Cylinder Bore Ridge Reamer
Courtesy of GENERAL MOTORS CORP.	J 25033-C Power Steering Pump Pulley Installer
Courtesy of GENERAL MOTORS CORP.	J 25034-C Power Steering Pump Pulley Remover
Courtesy of GENERAL MOTORS CORP.	J 28410 Gasket Remover
Courtesy of GENERAL MOTORS CORP.	J 28428-E Leak Detector Kit
Courtesy of GENERAL MOTORS CORP.	J 33049 Camshaft Bearing Service Set
Courtesy of GENERAL MOTORS CORP.	J 35667-A Cylinder Leakdown Tester
Courtesy of GENERAL MOTORS CORP.	J 36221 Hydraulic Clutch Line Separator
Courtesy of GENERAL MOTORS CORP.	J 37378-1 Valve Guide Reamer
Courtesy of GENERAL MOTORS CORP.	J 38606 Valve Spring Compressor - Head On-Vehicle
Courtesy of GENERAL MOTORS CORP.	J 38836 Pilot Bushing Installer/Clutch
Courtesy of GENERAL MOTORS CORP.	J 39580 Engine Support Table
Courtesy of GENERAL MOTORS CORP.	J 39580-500 Engine Support Table Top
Courtesy of GENERAL MOTORS CORP.	J 41476 Front and Rear Cover Alignment - at Crankshaft Seal Area
Courtesy of GENERAL MOTORS CORP.	J 41478 Crankshaft Front Oil Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 41479 Crankshaft Rear Oil Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 41480 Front and Rear Cover Alignment - at Oil Pan Surface
Courtesy of GENERAL MOTORS CORP.	J 41556 Connecting Rod Guide
Courtesy of GENERAL MOTORS CORP.	J 41558 Crankshaft Sprocket Remover
Courtesy of GENERAL MOTORS CORP.	J 41665 Crankshaft Balancer and Sprocket Installer
Courtesy of GENERAL MOTORS CORP.	J 41712 Oil Pressure Switch Socket
Courtesy of GENERAL MOTORS CORP.	J 41798 Engine Lifting Brackets
Courtesy of GENERAL MOTORS CORP.	J 41816 Crankshaft Balancer Remover
Courtesy of GENERAL MOTORS CORP.	J 41816-2 Crankshaft End Protector
Courtesy of GENERAL MOTORS CORP.	J 41818 Crankshaft Bearing Cap Remover
Courtesy of GENERAL MOTORS CORP.	J 42188 Ball Joint Separator
Courtesy of GENERAL MOTORS CORP.	J 42203 Driveline Support
Courtesy of GENERAL MOTORS CORP.	J 42385-100 Head/Main Bolt Thread Repair Kit
Courtesy of GENERAL MOTORS CORP.	J 42385-200 Common Thread Repair Kit
Courtesy of GENERAL MOTORS CORP.	J 42385-300 Fixtures and Hardware Kit
Courtesy of GENERAL MOTORS CORP.	J 42386-A Flywheel Holding Tool
Courtesy of GENERAL MOTORS CORP.	J 42907 Oil Pressure Testing Tool
Courtesy of GENERAL MOTORS CORP.	J 43276 Clutch Pilot Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 43690 Rod Bearing Checking Tool
Courtesy of GENERAL MOTORS CORP.	J 43690-100 Rod Bearing Checking Tool - Adapter Kit
Courtesy of GENERAL MOTORS CORP.	J 45059 Angle Meter
Courtesy of GENERAL MOTORS CORP.	J 45299 Engine Preluber
