Installation Procedure

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Connect the antenna lead to the antenna base.
    Fig 1: Installing Mast To Antenna Base
    G01813179Courtesy of GENERAL MOTORS CORP.
  2. Run the antenna lead through the fender hole
  3. Align the lead with the antenna base.
    NOTE: Refer to FASTENER NOTICE .
  4. Tighten the locking nut and fasten the antenna base to the fender.

    Tighten

    Tighten the nut to 5 N.m (44 lb in).

    Fig 2: Locking Nut & Antenna Base
    G01813180Courtesy of GENERAL MOTORS CORP.
