Section 786 (Instrument Panel, Gauges & Console): Specifications
WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Center Air Distribution Extension Duct Nuts | 10 N.m | 89 lb in |
| Cross Car Beam Bolts/Screws | 25 N.m | 18 lb ft |
| Data Link Connector Bolts/Screws | 2 N.m | 18 lb in |
| Defroster Duct Bolts/Screws | 10 N.m | 89 lb in |
| Driver Information Display to Overhead Console Bolts | 1 N.m | 9 lb in |
| Front Floor Console Bracket Bolts/Screws | 2.5 N.m | 22 lb in |
| Front Floor Console Bracket Lower Nuts | 10 N.m | 89 lb in |
| Front Floor Console Upper Bolts/Screws | 2.5 N.m | 22 lb in |
| Heater A/C Controls Bolts/Screws | 2.5 N.m | 22 lb in |
| Hood Release Handle Bolts/Screws | 2 N.m | 18 lb in |
| Instrument Panel Accessory Trim Plate Screws | 2 N.m | 18 lb in |
| Instrument Panel Bolts/Screws | 10 N.m | 89 lb in |
| Instrument Panel Cluster Screws | 2.5 N.m | 22 lb in |
| Instrumetn Panel Compartment Latch Screws | 1 N.m | 9 lb in |
| Instrument Panel Compartment Screws | 2.5 N.m | 22 lb in |
| Instrument Panel Lower Brace Bolts/Screws | 2 N.m | 18 lb in |
| Knee Bolster Bolts/Screws | 2.5 N.m | 22 lb in |
| Outside Ambient Air Temperature Sensor to Radiator Support Bolt | 2 N.m | 18 lb in |
| Radio Bolts/Screws | 2.5 N.m | 22 lb in |
| Switch Bank Bolts/Screws | 2.5 N.m | 22 lb in |
