Engine Mount Strut and Air Conditioning Compressor Bracket Removal (B Van, U Van, W Car)

WARNING: This page is about a different car, the 2002 Pontiac Montana, 2002 Oldsmobile Silhouette, and 2002 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the engine mount strut and A/C compressor bracket bolts.
  2. Remove the engine mount strut and A/C compressor bracket.
    Fig 1: Engine Mount Strut & Air Conditioning Compressor Bracket
    G01828880Courtesy of GENERAL MOTORS CORP.
