Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the oil pan. Refer to OIL PAN REPLACEMENT   .
  2. Remove the thermo element pins and washers (120 and 123).
  3. Remove the thermo element (121) and the thermo element plate (122).
    Fig 1: Removing Thermo Element Pins, Washers, Thermo Element And Thermo Element Plate
    G01531408Courtesy of GENERAL MOTORS CORP.
